Breakthrough 2x2, Dual-Polarity Design

airMAX® Omni Antennas are the first of their kind to feature a patented, dual-polarity omni design.

Powerful Omnidirectional Coverage

airMAX® Omni Antennas provide 360° coverage, 2x2 MIMO performance in Line-of-Sight (LOS) or Non-Line-of-Sight (NLOS) applications.

Industrial-Strength Construction

airMAX® Antennas are designed with robust mechanical design for outdoor application use.

Plug and Play Integration

Every airMAX® Antenna has a built-in Rocket™ mount, so no tools are needed to install the Rocket BaseStation.

Specifications

• Antenna Gain: 13dBi
• Beam-width: 360°
• Connector: 2x RP SMA Female
• Frequency Range: 2.35GHz – 2.55GHz
• Polarization: Vertical & Horizontal
• Wind Loading: 111.2N @ 200km/h
• Dimensions: 1390 x 122 x 105mm
• Weight: 2.4kg
