Features:

• -Meets 85% Efficiency
• -SATA Array Cable, Easy Installation
• -Active PFC
• -2013 ErP/EuP Ready

Specifications:

• -Model: HP500S
• -Rated Output Power: 500W
• -Form Factor: ATX 12V V2.4 & EPS 12V V2.92
• -Input Voltage: 200-240Vac
• -Input Current: 4A
• -Input Frequency: 50-60Hz
• -PFC: Active PFC (>0.9 typical)
• -Efficiency: Meet 85% @ Typical Load
• -Fan Type: 120mm Sleeved Fan
• -Noise: < 19dBA
• -Dimensions (LxWxH): 150 x 140 x 86 mm
• -Operation Temp.: 0 40 C / 32F 104F
• -Protection: OVP/OCP/SCP
• -Safety Approval: CE/TUV/KC/RCM/EAC

Connectors:

• -20+4 PIN x1
• -4+4 PIN x1
• -PCI-E 6+2 PIN x2
• -SATA x6
• -MOLEX x3
• -FLOPPY x1
