Performance

• # of Cores: 4
• # of Threads: 8
• Processor Base Frequency: 3.50 GHz
• Max Turbo Frequency: 3.90 GHz
• Cache: 8 MB
• Bus Speed: 8 GT/s DMI3
• TDP: 72 W
• VID Voltage Range: 0.55V-1.52V

Memory

• Max Memory Size (dependent on memory type): 64 GB
• Memory Types: DDR4-2400, DDR3L-1866
• Max # of Memory Channels: 2
• Max Memory Bandwidth: 37.5 GB/s
• ECC Memory Supported: Yes

Graphics

• Processor Graphics: None ‡

Expansion Options

• Scalability: 1S Only
• PCI Express Revision: 3.0
• PCI Express Configurations: 1x16, 2x8, 1x8+2x4 ‡
• Max # of PCI Express Lanes: 16

Package

• Sockets Supported: FCLGA1151
• Max CPU Configuration: 1
• Package Size: 37.5mm X 37.5mm

Advanced Technologies

• Intel® Optane™ Memory Supported: Yes ‡
• Intel® Turbo Boost Technology: 2.0 ‡
• Intel® vPro™ Technology: Yes ‡
• Intel® Hyper-Threading Technology: Yes ‡
• Intel® Virtualization Technology (VT-x): Yes ‡
• Intel® Virtualization Technology for Directed I/O (VT-d): Yes ‡
• Intel® VT-x with Extended Page Tables (EPT): Yes ‡
• Intel® TSX-NI: Yes
• Intel® 64: Yes ‡
• Instruction Set: 64-bit
• Instruction Set Extensions: SSE4.1/4.2, AVX 2.0
• Idle States: Yes
• Enhanced Intel SpeedStep® Technology: Yes
• Thermal Monitoring Technologies: Yes

Intel® Data Protection Technology

• Intel® AES New Instructions: Yes
• Secure Key: Yes
• Intel® Software Guard Extensions (Intel® SGX): Yes
• Intel® Memory Protection Extensions (Intel® MPX): Yes
